Step 1: Create my application

In order to run the development environment normally, you need to create an application and obtain the corresponding [application ID], [App security key] and [Message service address], the specific steps are as follows：

1.Click to enter Feitian Intelligent IOT platform login page, log in to Feitian Intelligent IOT platform.

2.In the list on the left side of the management platform, click [Add Application] to jump to the add application interface to add an application.

3.Enter [application name], application description (optional), click the [Save] button, the page jumps to the application list to view the newly added application’s [application ID] [App security key] [Message service address] and other key information , These parameters are needed during API initialization.

Step 2: Download the Java SDK, please click the download icon below：

Step 3: Initialization

Request interface：public static void init(String serverUrl, String appKey, String appSecret)

Interface function: To integrate with the Feitian Intelligent IoT platform through Feitian’s Java SDK, the initialization interface needs to be called first, and this interface only needs to be called once.

parameter name	Parameter Description
serverUrl	Application service address
appKey	Application ID
appSecret	App security key

parameter name	Parameter Description
nothing	nothing

JAVA



															import com.ft.iot.sdk.CustomerApi;



															public static void main(String[] args) {
																String serverUrl = "<Your serverUrl>";
																String appKey = "<Your appkey>";
																String appSecret = "<Your appsecret>";
																CustomerApi.init(serverUrl, appKey, appSecret);
															}

Step 4: Integrate the interfaces you need

After the initialization is complete, you can perform interface integration according to your business needs, please refer to the SDK interface for details

SDK initialization

Request interface： public static void init(String serverUrl, String appKey, String appSecret)

parameter name	Parameter Description
serverUrl	Application service address
appKey	Application ID
appSecret	App security key

parameter name	Parameter Description
nothing	nothing

JAVA



											import com.ft.iot.sdk.CustomerApi;



											public static void main(String[] args) {
												String serverUrl = "<Your serverUrl>";
												String appKey = "<Your appkey>";
												String appSecret = "<Your appsecret>";
												CustomerApi.init(serverUrl, appKey, appSecret);
											}

Device binding

Request interface： public static string bindDevice(String deviceSN, String paycode)

Interface function: bind the terminal device and the merchant's QR code plate. Upload the device number and QR code plate identification to the message service platform. After the verification is passed, bind the device and code plate.

parameter name	Parameter Description
deviceSN	device ID
paycode	Money collection code (the content of the QR code of the money collection code)

parameter name	Parameter Description
code	Return response code
msg	Result description
nonce	The nonce when requested, bring it back as it is
sign	Signature of response data Base64 (HmacSHA256 (parameter to be signed, appsecret)) The generation rules of the parameters to be signed are the same as the generation rules of the request signature

JAVA



														import com.ft.iot.sdk.CustomerApi;



														public static void main(String[] args) {
															String deviceSN = "<Your device number>";
															String paycode = "<Your payment code>";
															CustomerApi.bindDevice(deviceSN, paycode);
														}

Message push (using device code)

Request interface：public static String push(String deviceSN, int message, int pushTemplate)

Interface function: Push messages to specified devices.

parameter name	Parameter Description
deviceSN	Device number, you can specify the device number to push messages to the device
message	Broadcast amount, int type, unit: cent
pushTemplate	Voice template (5 Alipay; 6 WeChat; 7 Scan (default); 8 UnionPay)

parameter name	Parameter Description
code	Return response code
msg	Result description
nonce	The nonce when requested, bring it back as it is
pushsn	Message serial number
sign	Signature of response data Base64 (HmacSHA256 (parameter to be signed, appsecret)) The generation rules of the parameters to be signed are the same as the generation rules of the request signature

JAVA



														import com.ft.iot.sdk.CustomerApi;



														public static void main(String[] args) {
															String deviceSN = "<Your device number>";
															Integer message = "<Announced amount>";
															Integer pushTemplate = "<Your template number>";
															CustomerApi.push(deviceSN, message, pushTemplate);
														}

Message push (using the code plate number)

Request interface：public static String pushByPaycode(String paycode, int message, int pushTemplate)

Interface function: push voice messages to specified devices.

parameter name	Parameter Description
paycode	Collection code, specify the collection code, and push messages to the bound device
message	Broadcast amount, int type, unit: cent
pushTemplate	Voice template (5 Alipay; 6 WeChat; 7 Scan (default); 8 UnionPay)

parameter name	Parameter Description
code	Return response code
msg	Result description
pushsn	Message serial number
nonce	The nonce when requested, bring it back as it is
sign	Signature of response data Base64 (HmacSHA256 (parameter to be signed, appsecret)) The generation rules of the parameters to be signed are the same as the generation rules of the request signature

JAVA



														import com.ft.iot.sdk.CustomerApi;



														public static void main(String[] args) {
															String paycode = "<Your payment code>";
															Integer message = "<Announced amount>";
															Integer pushTemplate = "<Your message template number>";
															CustomerApi.pushByPaycode(paycode, message, pushTemplate);
														}

Get code plate binding device

Request interface： public static String getBindDevice(String paycode)

Interface function: Obtain the device information bound to the code plate.

parameter name	Parameter Description
paycode	Money collection code (the content of the QR code of the money collection code)

parameter name	Parameter Description
code	Return response code
msg	Result description
deviceSN	device ID
nonce	The nonce when requested, bring it back as it is
sign	Signature of response data Base64 (HmacSHA256 (parameter to be signed, appsecret)) The generation rules of the parameters to be signed are the same as the generation rules of the request signature

parameter name	Parameter Description
code	Return response code
msg	Result description
pushsn	Message serial number
nonce	The nonce when requested, bring it back as it is
sign	Signature of response data Base64 (HmacSHA256 (parameter to be signed, appsecret)) The generation rules of the parameters to be signed are the same as the generation rules of the request signature

JAVA



														import com.ft.iot.sdk.CustomerApi;



														public static void main(String[] args) {
															String paycode = "<Your payment code>";
															CustomerApi.getBindDevice(paycode);
														}

Get device information

Request interface：public static String getDeviceInfo(String deviceSN)

Interface function: check the information of a specified device.

parameter name	Parameter Description
deviceSN	device ID

parameter name	Parameter Description
code	Return response code
msg	Result description
status	The binding status of the device (0 is not bound, 1 is bound)
state	Device status (0 normal, 1 disabled)
is_online	Whether online (0 online, 1 offline)
version	current version
last_online_time	Last online time
last_offline_time	Last offline time
location_info	Device location information, for example: {"descp","Xueqing Road, Haidian District, Beijing, near Huizhi Building"}}
nonce	The nonce when requested, bring it back as it is
sign	Signature of response data Base64 (HmacSHA256 (parameter to be signed, appsecret)) The generation rules of the parameters to be signed are the same as the generation rules of the request signature

JAVA



														import com.ft.iot.sdk.CustomerApi;



														public static void main(String[] args) {
															String deviceSN = "<Your device number>";
															CustomerApi.getDeviceInfo(deviceSN);
														}

Unbind device

Request interface：public static String unbindDevice(String deviceSN)

Interface function: release the binding relationship between the terminal device and the QR code plate.

parameter name	Parameter Description
deviceSN	device ID

parameter name	Parameter Description
code	Return response code
msg	Result description
nonce	The nonce when requested, bring it back as it is
sign	Signature of response data Base64 (HmacSHA256 (parameter to be signed, appsecret)) The generation rules of the parameters to be signed are the same as the generation rules of the request signature

JAVA



														import com.ft.iot.sdk.CustomerApi;



														public static void main(String[] args) {
															String deviceSN = "<Your device number>";
															CustomerApi.unbindDevice(deviceSN);
														}
